OSN002N01 Is Huawei MA5800T 100GE Optical Module QSFP28-100G-CWDM4-LC-SMF-2km
OSN002N01:High Speed Transceiver,QSFP28,1310nm,100G,-6.5dBm,2.5dBm,-10dBm,LC,SMF,2Km,CWDM4
Basic information about the OSN002N01
|
Item |
Value |
|
Basic Information |
|
|
Module name |
QSFP28-100G-CWDM4-LC-SMF-2km |
|
Part Number |
34061299 |
|
Model |
OSN002N01 |
|
Form factor |
QSFP28 |
|
Connector type |
LC |
|
Optical fiber type |
SMF |
|
Working case temperature [°C] |
0 °C ~ 70 °C |
|
Transmission rate [bit/s] |
100 Gbit/s |
|
Target transmission distance [km] |
2 km |
|
Supply Voltage |
3.3 V +/-5% |
Transmitter Optical Characteristics
|
Center wavelength [nm] |
1271 nm 1291 nm 1311 nm 1331 nm |
|
Tx operating wavelength range [nm] |
1264.5 nm - 1277.5 nm 1284.5 nm - 1297.5 nm 1304.5 nm - 1317.5 nm 1324.5 nm - 1337.5 nm |
|
Minimum Tx optical power (AVG) [dBm] |
each channel: -6.5 dBm |
|
Maximum Tx optical power (AVG) [dBm] |
each channel: 2.5 dBm |
|
Minimum extinction ratio [dB] |
each channel: 3.5 dB |
Receiver Optical Characteristics
|
Rx sensitivity (AVG) [dBm] |
- |
|
Overload power (AVG) [dBm] |
2.5 dBm |
|
Maximum Rx Optical Power (AVG) [dBm] |
each channel: 2.5 dBm |
|
Minimum Rx Optical Power (AVG) [dBm] |
each channel: -11.5 dBm |
|
Rx sensitivity (OMA) [dBm] |
each channel: -10 dBm |
